ITEM
QUANTITY
PART NUMBER
DESCRIPTION
13
1
02752501
TOOLBOX WITH TOTE TRAY
20
24
02939900
SCREW, CAP HEX HD 5/16-18 X 3/4
21
2
02994600
SCREW, CAP HEX HD 5/8-11 X 4-1/2
24
1
09995000
DEVICE, TRAILER LOCATING
26
1
44226400
TUBING HEAT SHRINK, POLY 3/4" X 4"
27
1
44298500
JETTER LICENSE PLATE INSERT
28
16
522132-00
NUT, NYLOCK 3/8-16
29
1
543801-01
TUBING-PVC CLEAR 7/8 I.D. X 1/8
30
1
585431-01
DECAL, WARNING UNTRAINED PERSON
31
1
585463-01
DECAL, WARNING BAT. EXPLOSION HA
33
2
71108100
DECAL, SPARTAN 717
34
1
71705500
SCREW, HEX HD 1/4-20 X 1-1/4
37
7
72715100
CLAMP, 1-1/8" STEEL, PLASTIC COATED
38
1
73802700
RELL, FILL HANNAY
39
10
73808690
LUG NUT, 1/2" 3/4" HEX SS
40
2
73809700
REFLECTOR, SIDE 738
41
1
73815300
CABLE, BATTERY (NEGATIVE) 32" LG BLK
42
1
73816500
ADAPTER, SWIVEL 3/8 M X 3/8 F"
45-51
2
73826800
WIRE-LOOM, BLACK PLASTIC 3/8"
53
8
73829700
U-BOLT SQUARE 2" WIDE X 2-5/8
54
2
73830100
SCREW, FLAT HD 1/4-20 X 1-1/2
55
1
73830400
WASHER, FLAT 7/8 SAE
56
2
73831200
CLAMP, HOSE 1-1/16" - 2" #24
57
1
73832400
SCREW, HEX HD 3/8-16 X 4-3/4
58
2
73837800
PLUG, 3/8 BLACK PLASTIC
59
1
74311900
CAP, LIQUID LEVEL SENSOR
60
1
74311940
WELDMENT, 20 GAL TANK FOR ANTIFREEZE
61
1
75715300
THROTTLE CONTROL, DC MOTOR
62
2
75729040
LANYARD, SPARTAN KEY RING
63
2
75760072
LIGHT, LED, RED
64
2
75760073
LIGHT, AMBER MARKER (LED)
65
1
75800850
NOZZLE, CLOSED 4k@10
66
1
75800950
NOZZLE, OPEN 4K@10
67
1
75814760
STRAP, NYLON BATTERY HOLD DOWN
69
1
75815301
BOX, BATTERY
71
1
75840100
WELDMENT, SOLDIER FRAME
72
1
75840200
AXLE, TORFLEX #10 (3,500 LBS)
73
2
75840310
TIRE & ALUM WHEEL 14" 5 LUG
74
4
75840591
RUBBER BUMPER, 3/8-16 THREADED
75
1
75841000
FIBERGLASS SHELL, 758 W/HARDWARE
76
1
75841010
VINYL EDGE TRIM, 5/8" BLACK
77
1
75841605
ASSY, 200 GAL WATERTANK
78
1
75841650
ASSY, GARDEN HOSE X 2" CAM LOCK
79
1
75842440
FILL CAP, UN-VENTED ANTIFREEZE
80
2
75842900
SHOULDER BOLT, 1/2" X 1-1/2"
81
2
75843900
WELDMENT, TANK SUPPORT
82
2
75844030
WELDMENT, TANK DECK SUPPORT
83
2
75844200
CANNEL, UPPER WATERTANK
84
1
75844300
GRILL, 758 ENCLOSURE
85
2
75844700
MUDFLAP, SOLDIER W/SPARTAN LOGO
86
1
75845400
PLATE, 758 WATERTANK COVER
87
1
75846500
WELDMENT, UPPER GRILL SUPPORT
88
1
75848020
NIPPLE, HEX 1/2" BRASS
89
2
75850500
PLATE, MUDFLAP
90
2
75851600
PLATE, REEL UPPER SUPPORT WASH
91
23
75852030
SCREW, 1/4-20 X 1/2" BUTTON HD
92
6
75852050
1/4 X 1.5 FLANGED
93
9
75852060
NUT, 3/8-16 FLANGED
94
9
75852500
WASHER, 2" X 2" X .25" BLACK
95
6
75852600
WASHER, SQUARE, STEEL 9/16" I.D.
96
19
75853000
HEX HD BOLT 3/8-16 X 4 GRD8
97
2
75853010
HEX HD BOLT 1/2-13 X 5 GRD8
98
1
75853340
REDUCING NIPPLE, 1/2" TO 3/8" HP
99
1
75853370
3/8" SWIVEL FITTING 45, STEEL
100
2
75853700
GAS STRUT, 33.94" X M8 25 LBS
101
4
75853710
10MM GAS STRUT MOUNTING SOCKET
102
1
75854010
DECAL, JACK CASTER WARNING
103
1
75854030
DECAL, SOLDIER REAR BUMPER
104
2
75854050
DECAL, ELITE SOLDIER TOOL BOX SIDE
105
1
75854060
DECAL, ELITE SOLDIER FRONT FIBERGLASS
106
1
75854070
DECAL, ELITE SOLDIER TOOLBOX REAR
107
1
75854150
HARNESS, TRAILER SOLDIER P&P
108
2
75858840
TERMINAL, BUTT SPLICE 10-12 AWG
109
11
75858890
CONNECTOR, BUTT SPLICE CRMP HT SHRINK 16-14 AWG
110-111
1
75860900
SOLDIER ENCLOSURE
112
2
75864100
HOSE, 3/8" I.D. X 350' GREEN
113
1
75866500
ASSY, 3/8" ANTI-TURN AROUND
115
1
75868400
HP REEL FRAME WELDMENT
116
1
75868500
HP MAIN SUPPORT WELDMENT
117
2
75868600
REAR UPRIGHT WELDMENT
118
1
75868650
PLATE, INDEX - HP REEL
119
1
75868700
PIVOT PIN. WELDMENT, 14"
120
4
75868880
WASHER 7/8" ID X 1-3/8" OD
121
1
75870000
ASSY, HP REEL
122
2
75870200
BLOCK, REST POSITION SPRT
123
1
75870300
ANGLE, BLOCK REST POS HP REEL
124
1
75870400
ANGLE, REEL TRANSIT SPRT
125
1
75870500
ANGLE, REEL LATCH
126
1
75870700
ASSY, SOLDIER TOOLBOX
ITEM
QUANTITY
PART NUMBER
DESCRIPTION
127
1
75871500
ASSY, HOSE GUIDE
128
1
75871600
TANK, 8 GAL GAS
129
1
75871700
WELDMENT, 8 GAL GAS TANK
130
2
75871800
STRAP, 8 GAL GAS TANK
131
1
75872000
ASSY, INDEX LATCH
132
2
75874005
LATCH, LOCKABLE OVER CENTER
133
2
75874010
CLASP, LOCKABLE OVER CENTER
134
2
75874015
CLEVIS, 3/8" X 1-1/2" ZINC
135
4
75874020
GROMMET, 1-1/4" X .125" THICK
136
1
75874035
CABLE, HOLD 3/8" RING X 22"
137
1
75874040
CABLE ASSY., THROTTLE ELITE
138
1
75874060
DECAL, ELITE RECIRC VALVE
139
1
75874100
ASSY., UNLOADER RECIRC ELITE
140
1
75874150
ASSY., LOW PSI VALVE - MANUAL ELITE
141
1
75874300
WELDMENT, HP RECIRC BOX UPPER
142
1
75874310
WELDMENT, HP RECIRC BOX LOWER
143
1
75874320
ASSY., RIONED ACTUATOR SIDE MOUNT FOR ELITE SOLDIER
144
1
75874350
ASSY., WATER TANK DRAIN ELITE
145
1
75874400
BRACKET, CONTROL BOX ELITE
146
1
75874410
CONTROL BOX, ELITE SOLDIER
147
1
75874411
HARNESS, ELITE SOLDIER POWER
148
1
75874412
HARNESS, ELITE SOLDIER ENGINE
149
1
75874413
SENSOR HARNESS
150
1
75874414
HARNESS, ELITE SOLDIER REMOTE
151
1
75874416
HARNESS, INLINE STARTER RELAY ELITE REMOTE
152
1
75874500
ASSY., POWER PACK ELITE SOLDIER
153
1
75874520
WELDMENT, UNI AF/GAS TANK MNT
154
1
75874570
TACH, EFI ENGINE
155
1
75879190
ASSY, SOLDIER REEL LOCK
158
1
77711301
TEE, MALE RUN 1/2" M & F NPT
160
8
77726500
RIVET, POP-3/16" X 3/16" GRIP LENGTH, STEEL
161
1
77728900
CAP, CABLE
166
10
77743400
WASHER LOCK-SPLIT MEDIUM 5/16"
168
3
77746000
CLAMP, HOSE 7/32 - 5/8 S.S.
169
3
77747800
LOCKNUT, STOVER 5/16-18 UNC ZINC PLTD
170
52
77748000
NUT, STOVER LOCK 3/8-16 UNC
171-173
3
77748200
HOSE, 1-1/2" X 4 SPIRAL
175
2
77763500
DECAL, CRANK
177
12
77767600
CLAMP, HOSE 11/16 - 1-1/4 S.S. WORM DRIVE
178
6
77785200
MOUNT, MOTOR
180
1
77799825
HOSE ASSY, WASH DOWN KIT
181
1
77800600
ASSY, HOSE GUARD 2"
183
2
79824400
SCREW, SOCK HD CAP 1/4-20 X 1.5
184
1
79827300
HAND CRANK, HP REEL
185
1
79827900
TUBING, HEAT SHRINK 1.1":3/8" RED
186
22
79838800
NUT, FLANGED 5/16-18
187
19
79842200
CLAMP, HOSE 1/2
188
2
79843900
ELBOW, 1/2" NPT X 3/4" BARB
189
1
79847800
BATTERY, 850 CCA
191
2
79854500
NUT, 5/8-11 HEX LOCK
192
7
79860000
CLAMP, VINYL COATED 5/8"
193
1
79866600
ANTIFREEZE, PINK RV
194
2
79868500
CLAMP, HOSE 2" VINYL COATED
195
1
79900601
CORD, 7 POLE QUICK RELEASE 6'
196
1
79904200
BREAKAWAY KIT, WITH CHARGER
197
1
79904410
VALVE, 1/2" BRASS 3 WAY
198
1
79904475
VALVE, RELIEF BRONZE 50-175PSI
200-202
3
79904497
HOSE, 3/4" CLEAR
204
2
79908100
SCREW, HEX HD 1/4-20 X 3
205
4
79908200
WASHER, FLAT 1/4 SAE
206
4
79917150
STRAP, 20 GAL FUEL
207
2
79920140
SCREW, 1/2-13 X 4-1/2 HX GR8
208
2
79920145
SCREW, 1/2-13 X 1-1/2 GR8
209
6
79920150
SCREW, 3/8-16 X 1-1/2 HX GR8
210
1
79920154
SCREW, HEX HD CAP 1/4-20X2"
211
1
79920160
SCREW, 3/8-16 X 1-1/2 HX GR8
212
8
79920161
WASHER, FLAT 5/8 GR8
213
4
79920162
NUT, HEX TOP LOCK 5/8-18 GR C
214
1
79920185
CABLE, BAT RED POS 48" 2 GA
215
1
79920243
WELDMENT, CLUTCH ACTUATOR BRKT
216
1
79920628
BALL STUD, 10MM - 5/16-18 THRD
217
2
79920720
BREAKLIGHT, OVAL LAMP
218
1
79921400
TANK, ANTIFREEZE
219
2
79922570
BALL JOINT END
220
1
79931380
ELBOW, 1-1/4" POLY 45DEG STREET
221
7
79942600
WASHER, FLAT SAE 1/2", 0.074 THK
222
4
79942700
NUT, HEX JAM 1/2-20 - 5/16 HT
223
2
79943100
WASHER, 17/32 I.D., 2" O.D.
225
4
79945830
REFLECTOR-RED
226
1
79947640
BRACKET, 7PIN RECEPTICLE
227
1
79948250
PLUG, 2POS DEUTSCH
228
2
79948251
FEMALE SOCKET, 16-20 DEUTSCH
229
1
79948252
WEDGE, PLUG 2POS DEUTSCH
230, 231
1
79950000
HOSE, HP REEL INLET HOSE
232
1
79952100
DECAL, VIN NUMBER
233
1
79952200
DECAL, TIRE & LOADING
234
1
79952300
DECAL, WHEEL & LUG NUTS
235
1
79952400
DECAL, SAFETY CHAIN
236
1
79952700
DECAL, NATM COMPLIANCE
238
2
79953826
D BATTERY
239
1
79953840
ELECTRIC PULSATOR ASSY. - 2016
240
5
79959500
3/4" HOSEBARB X 1/2" MPT ELB BR
241
1
79959605
DECAL, WATER VALVE
242
1
79959610
DECAL, DRAIN VALVE
246
2
79962300
CLAMP, INSULATED 7/8"
247
1
79962310
CLAMP, INSULATED 1-1/2" I.D.
248,249
1
79962321
HOSE, RBBR 1-1/2" OD -1-1/4 ID
250
1
79966200
FLEX HEAT SHRINK TUBING
251
1
79966310
PIN, LOCKING 3/8 DIA 1-3/8
252
1
79966500
COUPLER, 2" EZ-LATCH
253
1
79966551
WELDMENT, DROP COUPLER
254
1
79976230
VALVE SPACER INNER
255
1
79976235
VALVE SPACER OUTER
256
4
79976241
SCREW, M6 X 65MM HEX HD
