ITEM
QUANTITY
PART NUMBER
DESCRIPTION
12
1
02752501
TOOLBOX WITH TOTE TRAY
19
20
02939900
SCREW, CAP HEX HD 5/16-18 X 3/4
20
2
02994600
SCREW, CAP HEX HD 5/8-11 X 4-1/2
23
1
09995000
DEVICE, TRAILER LOCATING
26
1
44226400
TUBING HEAT SHRINK, POLY 3/4" X 4"
27
1
44298500
JETTER LICENSE PLATE INSERT
28
16
522132-00
NUT, NYLOCK 3/8-16
29
1
585463-01
DECAL, WARNING BAT. EXPLOSION HA
31
2
71108100
DECAL, SPARTAN 717
33
1
72714600
ELBOW, 90 DEG FEMALE 1/2 STEEL
34
4
72715100
CLAMP, 1-1/8" STEEL, PLASTIC COATED
35
1
72730300
NIPPLE, 1/2NPT X 3 SS
36
10
73808690
LUG NUT, 1/2" 3/4" HEX SS
37
2
73809700
REFLECTOR, SIDE 738
38
1
73815200
CABLE, BATTERY (POSITIVE) 40" LG RED
39
1
73816500
ADAPTER, SWIVEL 3/8 M X 3/8 F"
42, 43, 44
2
73826800
WIRE-LOOM, BLACK PLASTIC 3/8"
46
8
73829700
U-BOLT SQUARE 2" WIDE X 2-5/8
47
1
73830100
SCREW, FLAT HD 1/4-20 X 1-1/2
48
1
73831000
U-BOLT, 3" TUBE O.D. W/NUTS
49
6
73831200
CLAMP, HOSE 1-1/16" - 2" #24
50
1
73832400
SCREW, HEX HD 3/8-16 X 4-3/4
51
1
73838500
CABLE, NEGATIVE BATTERY-56" LG
52
1
74026400
VERNIER THROTTLE CONTROL
53
1
74311900
CAP, LIQUID LEVEL SENSOR
54
1
74311940
WELDMENT, 20 GAL TANK FOR ANTIFREEZE
55
2
75729040
LANYARD, SPARTAN KEY RING
56
2
75760072
LIGHT, LED, RED
57
2
75760073
LIGHT, AMBER MARKER (LED)
60
1
75814760
STRAP, NYLON BATTERY HOLD DOWN
62
1
75815301
BOX, BATTERY
64
1
75821300
SCREW, HEX HD M8 X 16MM
65
1
75829040
CONTROL BOX, SOLDIER
66
1
75829440
HARNESS, SOLDIER CONTROL BOX
67
1
75840100
WELDMENT, SOLDIER FRAME
68
1
75840200
AXLE, TORFLEX #10 (3,500 LBS)
69
2
75840310
TIRE & ALUM WHEEL 14" 5 LUG
70
4
75840591
RUBBER BUMPER, 3/8-16 THREADED
71
1
75841000
FIBERGLASS SHELL, 758 W/HARDWARE
72
1
75841010
VINYL EDGE TRIM, 5/8" BLACK
73
1
75841600
ASSY, 200 GAL WATERTANK
74
1
75841650
ASSY, GARDEN HOSE X 2" CAM LOCK
75
1
75842440
FILL CAP, UN-VENTED ANTIFREEZE
76
2
75842900
SHOULDER BOLT, 1/2" X 1-1/2"
77
1
75843500
SOLDIER STRAINER ASSY
78
1
75843600
PLATE, STRAINER MOUNT
79
2
75843900-US
WELDMENT, TANK SUPPORT
80
2
75844030
WELDMENT, TANK DECK SUPPORT
81
2
75844200
CANNEL, UPPER WATERTANK
82
1
75844300
GRILL, 758 ENCLOSURE
83
2
75844700
MUDFLAP, SOLDIER W/SPARTAN LOGO
84
1
75845400
PLATE, 758 WATERTANK COVER
85
1
75846500
WELDMENT, UPPER GRILL SUPPORT
86
1
75849800
HOSE, 1/2" HP PUMP TO REEL
87
2
75850500
PLATE, MUDFLAP
88
2
75851600
PLATE, REEL UPPER SUPPORT WASH
89
17
75852030
SCREW, 1/4-20 X 1/2" BUTTON HD
90
6
75852050
1/4 X 1.5 FLANGED
91
2
75852060
NUT, 3/8-16 FLANGED
92
9
75852500
WASHER, 2" X 2" X .25" BLACK
93
6
75852600
WASHER, SQUARE, STEEL 9/16" I.D.
94
21
75853000
HEX HD BOLT 3/8-16 X 4 GRD8
95
2
75853010
HEX HD BOLT 1/2-13 X 5 GRD8
96
1
75853400
ASSY, SOLDIER FILL REEL
97
2
75853700
GAS STRUT, 33.94" X M8 25 LBS
98
4
75853710
10MM GAS STRUT MOUNTING SOCKET
99
2
75854000
REAR TOOLBOX DECAL, SOLDIER
100
1
75854010
DECAL, JACK CASTER WARNING
101
1
75854020
DECAL, SOLDIER FRONT FIBERGLASS
102
1
75854030
DECAL, SOLDIER REAR BUMPER
103
1
75854040
DECAL, SOLDIER REAR TOOL BOX
104
1
75854150
HARNESS, TRAILER SOLDIER P&P
ITEM
QUANTITY
PART NUMBER
DESCRIPTION
105
2
75858840
TERMINAL, BUTT SPLICE 10-12 AWG
106
5
75858880
CONNECTOR, BUTT SPLICE CRMP HT SHRINK 12-10 AWG
107
2
75858890
CONNECTOR, BUTT SPLICE CRMP HT SHRINK 16-14 AWG
108, 109
3
75860900
SOLDIER ENCLOSURE
110
1
75864100
HOSE, 3/8" I.D. X 350' GREEN
111
2
75865000
BOLT, 5/16-18 X 2 1/2" HEX HD
112
1
75866500
ASSY, 3/8" ANTI-TURN AROUND
113
1
75868400
HP REEL FRAME WELDMENT
114
1
75868500
HP MAIN SUPPORT WELDMENT
115
2
75868600
REAR UPRIGHT WELDMENT
116
1
75868650
PLATE, INDEX - HP REEL
117
1
75868700
PIVOT PIN. WELDMENT, 14"
118
1
75869940
BRACKET, SOLDIER CONTROL BOX
119
1
75870000
ASSY, HP REEL
120
1
75870160
HOSE, 1/2 MNPT X 16 HP VALVE
121
2
75870200
BLOCK, REST POSITION SPRT
122
1
75870300
ANGLE, BLOCK REST POS HP REEL
123
1
75870400
ANGLE, REEL TRANSIT SPRT
124
1
75870500
ANGLE, REEL LATCH
125
1
75870700
ASSY, SOLDIER TOOLBOX
126
1
75871000
ASSY, RECIRC/THROTTLE
127
1
75871500
ASSY, HOSE GUIDE
128
1
75871600
TANK, 8 GAL GAS
129
1
75871700
WELDMENT, 8 GAL GAS TANK
130
2
75871800
STRAP, 8 GAL GAS TANK
131
1
75872000
ASSY, INDEX LATCH
132
1
75874520
WELDMENT, UNI AF/GAS TANK MNT
133
1
75879190
ASSY, SOLDIER REEL LOCK
134
1
75881300
BRACKET, WATER VALVE
135
1
75886000
POWER PACK, 26.5 HP EFI
139
1
77728900
CAP, CABLE
141
4
77738800
BUTT CONNECTOR 16GA
142
1
77739800
DECAL, CAUTION MANUAL/REEL
144
10
77743400
WASHER LOCK-SPLIT MEDIUM 5/16"
146
3
77746000
CLAMP, HOSE 7/32 - 5/8 S.S.
147
55
77748000
NUT, STOVER LOCK 3/8-16 UNC
150
1
77763500
DECAL, CRANK
152
10
77767600
CLAMP, HOSE 11/16 - 1-1/4 S.S. WORM DRIVE
153
4
77785200
MOUNT, MOTOR
155
1
77799825
HOSE ASSY, WASH DOWN KIT
156
1
77800600
ASSY, HOSE GUARD 2"
158
1
79824400
SCREW, SOCK HD CAP 1/4-20 X 1.5
159
1
79827300
HAND CRANK, HP REEL
160
1
79827900
TUBING, HEAT SHRINK 1.1":3/8" RED
161
24
79838800
NUT, FLANGED 5/16-18
162
17
79842200
CLAMP, HOSE 1/2
163
2
79843900
ELBOW, 1/2" NPT X 3/4" BARB
164
1
79847800
BATTERY, 850 CCA
166
2
79854500
NUT, 5/8-11 HEX LOCK
167
4
79860000
CLAMP, VINYL COATED 5/8"
168
1
79866600
ANTIFREEZE, PINK RV
169
2
79900400
CON., 7 POLE - TRAILER END
170
1
79904200
BREAKAWAY KIT, WITH CHARGER
171
1
79904497
HOSE, 3/4" CLEAR
173
2
79908100
SCREW, HEX HD 1/4-20 X 3
174
2
79917150
STRAP, 20 GAL FUEL
175
2
79920140
SCREW, 1/2-13 X 4-1/2 HX GR8
176
2
79920145
SCREW, 1/2-13 X 1-1/2 GR8
177
6
79920150
SCREW, 3/8-16 X 1-1/2 HX GR8
178
4
79920160
SCREW, 3/8-16 X 1-1/2 HX GR8
179
8
79920161
WASHER, FLAT 5/8 GR8
180
4
79920162
NUT, HEX TOP LOCK 5/8-18 GR C
181
1
79920243
WELDMENT, CLUTCH ACTUATOR BRKT
182
4
79920628
BALL STUD, 10MM - 5/16-18 THRD
183
2
79920720
BREAKLIGHT, OVAL LAMP
184
1
79921400
TANK, ANTIFREEZE
185
2
79922570
BALL JOINT END
186
1
79931380
ELBOW, 1-1/4" POLY 45DEG STREET
187
3
79942600
WASHER, FLAT SAE 1/2", 0.074 THK
188
4
79942700
NUT, HEX JAM 1/2-20 - 5/16 HT
189
2
79943100
WASHER, 17/32 I.D., 2" O.D.
191
4
79945830
REFLECTOR-RED
192
1
79947640
BRACKET, 7PIN RECEPTICLE
193
1
79952100
DECAL, VIN NUMBER
194
1
79952200
DECAL, TIRE & LOADING
195
1
79952300
DECAL, WHEEL & LUG NUTS
196
1
79952400
DECAL, SAFETY CHAIN
197
1
79952600
DECAL, ELECTRIC BRAKES
198
1
79952700
DECAL, NATM COMPLIANCE
199
1
79952705
DECAL, 55 MPH SPEED LIMIT
201
2
79953826
D BATTERY
202
1
79959600
DECAL, ANTIFREEZE VALVE
203
1
79959605
DECAL, WATER VALVE
204
1
79959610
DECAL, DRAIN VALVE
208
6
79962300
CLAMP, INSULATED 7/8"
209
5
79962310
CLAMP, INSULATED 1-1/2" I.D.
210
1
79966200
FLEX HEAT SHRINK TUBING
211
1
79966310
PIN, LOCKING 3/8 DIA 1-3/8
212
1
79966500
COUPLER, 2" EZ-LATCH
213
1
79966551
WELDMENT, DROP COUPLER
